SN75240PWG4
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Circuit Protection / TVS - Mixed Technology
Description
IC DUAL USB PORT TVS 8-TSSOP
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Weight 39.008944mg
Technical
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Applications USB
Capacitance 35pF
Max Power Dissipation 60W
Technology Mixed Technology
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Terminal Pitch 0.65mm
Depth 4.5mm
Base Part Number SN75240
Pin Count 8
Operating Supply Voltage 6V
Working Voltage 6V
Temperature Grade COMMERCIAL
Number of Channels 4
Leakage Current 1μA
Number of Circuits 1
Element Configuration Dual
Breakdown Voltage 7V
Telecom IC Type SURGE PROTECTION CIRCUIT
Min Breakdown Voltage 7V
Dimensions
Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
