SN65240PWRG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-TSSOP (0.173, 4.40mm Width)
Category Circuit Protection / TVS - Mixed Technology
Description IC USB TRANSIENT SUPP 8-TSSOP
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 29997
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Weight 39.008944mg
Diode Element Material SILICON

Technical

Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications USB
Additional Feature LOW CAPACITANCE
Capacitance 35pF
Max Power Dissipation 60W
Technology Mixed Technology
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Depth 4.5mm
Base Part Number SN65240
Pin Count 8
Operating Supply Voltage 6V
Number of Elements 2
Working Voltage 6V
Polarity UNIDIRECTIONAL
Number of Channels 4
Leakage Current 1μA
Number of Circuits 1
Element Configuration Dual
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Breakdown Voltage 6V
Rep Pk Reverse Voltage-Max 6V
Min Breakdown Voltage 7V

Dimensions

Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
