SN65240P image
Favorite
SN65240P image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Circuit Protection / TVS - Mixed Technology
Description IC DUAL USB PORT TVS 8-DIP
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.722
≥1 USD $0.722
≥10 USD $0.5928
≥100 USD $0.5738
≥500 USD $0.55575
≥1000 USD $0.53675
Inventory: 19939
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 3.9mm
Width 6.35mm
Length 9.81mm
Height 5.08mm

Technical

Min Breakdown Voltage 7V
Rep Pk Reverse Voltage-Max 6V
Breakdown Voltage 7V
Peak Pulse Power 60W
Max Surge Current 3A
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Element Configuration Dual
Number of Circuits 1
Leakage Current 1μA
Number of Channels 4
Polarity UNIDIRECTIONAL
Working Voltage 6V
Number of Elements 2
Operating Supply Voltage 3.3V
Pin Count 8
Base Part Number SN65240
Depth 6.35mm
Technology Mixed Technology
Max Power Dissipation 60W
Capacitance 35pF
Additional Feature LOW CAPACITANCE
Applications USB
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination Through Hole
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube

Physical

Diode Element Material SILICON
Weight 440.409842mg
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
