ESDU03A5V5R17V image
Favorite
ESDU03A5V5R17V image
Favorite
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Circuit Protection / TVS - Mixed Technology
Description VARISTOR 17V 0603
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.22968
≥100 USD $0.115984
≥500 USD $0.102784
≥1000 USD $0.079992
≥3000 USD $0.071597
Inventory: 20647
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Voltage - Clamping 17V
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Number of Circuits 1
Configuration SINGLE
Polarity UNIDIRECTIONAL
Working Voltage 5.5V
Number of Elements 1
Operating Temperature (Min) -55°C
Case Code (Imperial) 0603
Case Code (Metric) 1608
Qualification Status Not Qualified
JESD-30 Code R-PDSO-R2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Form WRAP AROUND
Terminal Position DUAL
Technology Polymer
Applications General Purpose
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series ESDU
Published 2003
Packaging Tape & Reel (TR)

Physical

Diode Element Material SILICON
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
