P1101UCLTP
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Circuit Protection / TVS - Mixed Technology
Description
6-SMD Gull Wing TwinSLIC? 4 Surface Mount Mixed Technology Tvs 130V 2.2A 85C
PDF
/
Buying Options
Total Price: USD $7.62
Unit Price: USD $7.620072
≥1 USD $7.620072
≥200 USD $3.040676
≥500 USD $2.939583
≥1000 USD $2.889693
Inventory: 4451
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Surface Mount YES
Technical
Packaging Tube
Published 2004
Series TwinSLIC?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications SLIC
Technology Mixed Technology
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Terminal Pitch 3.505mm
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 6
JESD-30 Code R-PDSO-G6
Qualification Status Not Qualified
Working Voltage 95V
Temperature Grade AUTOMOTIVE
Number of Circuits 4
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 120mA
Voltage - Clamping 130V
Dimensions
Height Seated (Max) 2.36mm
Length 9.195mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
