P1101CA2
RoHS
/
Package DO-214AA, SMB (3 Leads), Compak
Category Circuit Protection / TVS - Mixed Technology
Description
SIDAC DL-CHP SLIC 95V 150A DO214
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.36005
≥1 USD $0.36005
≥10 USD $0.29545
≥100 USD $0.28595
≥500 USD $0.27645
≥1000 USD $0.2679
Inventory: 1174
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB (3 Leads), Compak
Surface Mount YES
Technical
Packaging Bulk
Published 2004
Series TwinSLIC?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications SLIC
Voltage - Rated DC 95V
Technology Mixed Technology
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.4mm
Reach Compliance Code unknown
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code R-PDSO-C3
Qualification Status Not Qualified
Working Voltage 95V
Temperature Grade INDUSTRIAL
Number of Circuits 2
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 120mA
Voltage - Clamping 130V
Dimensions
Length 4.395mm
Width 3.75mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
