B1201UC4LRP
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Circuit Protection / TVS - Mixed Technology
Description
BATTRAX SLIC DUAL NEG 500A MS013
PDF
/
Buying Options
Total Price: USD $13.38
Unit Price: USD $13.375825
≥1 USD $13.375825
≥200 USD $5.336939
≥500 USD $5.158384
≥1500 USD $5.07042
Inventory: 4225
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.49mm
Length 8.99mm
Height Seated (Max) 2.36mm
Technical
Voltage - Clamping Adjustable
Telecom IC Type SURGE PROTECTION CIRCUIT
Number of Circuits 1
Temperature Grade INDUSTRIAL
Working Voltage 4V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G6
Pin Count 6
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 5A
Reach Compliance Code unknown
Terminal Pitch 3.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology Mixed Technology
Voltage - Rated DC 4V
Capacitance 50pF
Voltage - Rated 4V
Applications SLIC
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Battrax?
Published 2005
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 21 Weeks
