B1101UC4LRP
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Circuit Protection / TVS - Mixed Technology
Description
BATTRAX SLIC DUAL NEG 500A MS013
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2004
Series Battrax?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Applications SLIC
Voltage - Rated 4V
Capacitance 50pF
Voltage - Rated DC 4V
Technology Mixed Technology
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 3.5mm
Reach Compliance Code unknown
Current Rating 5A
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 6
Qualification Status Not Qualified
Working Voltage 4V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Telecom IC Type SURGE PROTECTION CIRCUIT
Hold Current 100mA
Voltage - Clamping Adjustable
Dimensions
Length 8.99mm
Width 7.49mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
