824551221
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 22V 35.5V DO214AB
PDF
/
Inventory: 1889
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Technical
Number of Bidirectional Channels 1
Max Breakdown Voltage 25.65V
Bidirectional Channels 1
Breakdown Voltage 25.65V
Peak Pulse Power 3kW
Reverse Standoff Voltage 22V
Peak Pulse Current 84.5A
Voltage - Reverse Standoff (Typ) 22V Max
Clamping Voltage 35.5V
Voltage - Clamping (Max) @ Ipp 35.5V
Current - Peak Pulse (10/1000μs) 84.5A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 25.65V Typ
Power Line Protection No
Polarity Bidirectional
Applications General Purpose
Composition Zener
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series WE-TVSP
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Supplier Device Package DO-214AB
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
