824550102
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
DO-214AB SMC WE-TVSP 2 Surface Mount Zener Tvs Diode 117V 18.5A 3kW -65C~150C TJ
PDF
/
Inventory: 5762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Supplier Device Package DO-214AB
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Series WE-TVSP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Zener
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Zener
Applications General Purpose
Polarity Unidirectional
Power Line Protection No
Voltage - Breakdown (Min) 117V Typ
Power - Peak Pulse 3000W 3kW
Current - Peak Pulse (10/1000μs) 18.5A
Voltage - Clamping (Max) @ Ipp 162V
Clamping Voltage 162V
Voltage - Reverse Standoff (Typ) 100V Max
Peak Pulse Current 18.5A
Reverse Standoff Voltage 100V
Peak Pulse Power 3kW
Unidirectional Channels 1
Breakdown Voltage 117V
Max Breakdown Voltage 117V
Number of Unidirectional Channels 1
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
