824540241
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24V 38.9V DO214AB
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.745911
≥1 USD $0.745911
≥10 USD $0.703691
≥100 USD $0.66386
≥500 USD $0.626285
≥1000 USD $0.590832
Inventory: 1159
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Series WE-TVSP
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Number of Unidirectional Channels 1
Max Breakdown Voltage 28.1V
Breakdown Voltage 28.1V
Unidirectional Channels 1
Peak Pulse Power 1.5kW
Reverse Standoff Voltage 24V
Peak Pulse Current 38.6A
Voltage - Reverse Standoff (Typ) 24V Max
Clamping Voltage 38.9V
Voltage - Clamping (Max) @ Ipp 38.9V
Current - Peak Pulse (10/1000μs) 38.6A
Power - Peak Pulse 1500W 1.5kW
Voltage - Breakdown (Min) 28.1V Typ
Power Line Protection No
Polarity Unidirectional
Applications General Purpose
Composition Zener
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Physical
Supplier Device Package DO-214AB
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
