RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 12V 19.9V DO214AA
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.295553
≥1 USD $0.295553
≥10 USD $0.278822
≥100 USD $0.263038
≥500 USD $0.248157
≥1000 USD $0.234109
Inventory: 1115
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Supplier Device Package DO-214AA

Technical

Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Series WE-TVSP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Zener
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Zener
Applications General Purpose
Polarity Bidirectional
Power Line Protection No
Voltage - Breakdown (Min) 14V Typ
Power - Peak Pulse 600W
Current - Peak Pulse (10/1000μs) 30.2A
Voltage - Clamping (Max) @ Ipp 19.9V
Clamping Voltage 19.9V
Voltage - Reverse Standoff (Typ) 12V Max
Peak Pulse Current 30.2A
Reverse Standoff Voltage 12V
Peak Pulse Power 600W
Breakdown Voltage 14V
Bidirectional Channels 1
Max Breakdown Voltage 14V
Number of Bidirectional Channels 1

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
