824521111 image
Favorite
824521111 image
Favorite
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 11V 18.2V DO214AA
PDF
/
Inventory: 4263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Supplier Device Package DO-214AA

Technical

Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Series WE-TVSP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Zener
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Zener
Applications General Purpose
Polarity Bidirectional
Power Line Protection No
Voltage - Breakdown (Min) 12.85V Typ
Power - Peak Pulse 600W
Current - Peak Pulse (10/1000μs) 33A
Voltage - Clamping (Max) @ Ipp 18.2V
Clamping Voltage 18.2V
Voltage - Reverse Standoff (Typ) 11V Max
Peak Pulse Current 33A
Reverse Standoff Voltage 11V
Peak Pulse Power 600W
Breakdown Voltage 12.85V
Bidirectional Channels 1
Max Breakdown Voltage 12.85V
Number of Bidirectional Channels 1

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
