824520601
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 60V 96.8V DO214AA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264626
≥1 USD $0.264626
≥10 USD $0.249651
≥100 USD $0.235521
≥500 USD $0.22219
≥1000 USD $0.209611
Inventory: 4096
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 70.2V
Breakdown Voltage 70.2V
Unidirectional Channels 1
Peak Pulse Power 600W
Reverse Standoff Voltage 60V
Peak Pulse Current 6.2A
Voltage - Reverse Standoff (Typ) 60V Max
Clamping Voltage 96.8V
Voltage - Clamping (Max) @ Ipp 96.8V
Current - Peak Pulse (10/1000μs) 6.2A
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 70.2V Typ
Power Line Protection No
Polarity Unidirectional
Applications General Purpose
Composition Zener
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series WE-TVSP
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Supplier Device Package DO-214AA
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
