824520261
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 26V 42.1V DO214AA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.262764
≥1 USD $0.262764
≥10 USD $0.24789
≥100 USD $0.233865
≥500 USD $0.220628
≥1000 USD $0.208134
Inventory: 1282
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Supplier Device Package DO-214AA
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Series WE-TVSP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Zener
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Zener
Applications General Purpose
Polarity Unidirectional
Power Line Protection No
Voltage - Breakdown (Min) 30.4V Typ
Power - Peak Pulse 600W
Current - Peak Pulse (10/1000μs) 14.3A
Voltage - Clamping (Max) @ Ipp 42.1V
Clamping Voltage 42.1V
Voltage - Reverse Standoff (Typ) 26V Max
Peak Pulse Current 14.3A
Reverse Standoff Voltage 26V
Peak Pulse Power 600W
Unidirectional Channels 1
Breakdown Voltage 30.4V
Max Breakdown Voltage 30.4V
Number of Unidirectional Channels 1
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
