SMCJ12CA-E3/57T
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12V 19.9V DO214AB
PDF
/
Buying Options
Total Price: USD $3.36
Unit Price: USD $3.3573
≥1 USD $3.3573
≥10 USD $2.755
≥100 USD $2.66855
≥500 USD $2.58305
≥1000 USD $2.4966
Inventory: 1146
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 29 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Weight 211mg
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2008
Series TransZorb?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature UL RECOGNIZED; EXCELLENT CLAMPING CAPABILITY
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 12V
Max Power Dissipation 1.5kW
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SMCJ
Pin Count 2
Operating Supply Voltage 12V
Number of Elements 1
Leakage Current 5μA
Element Configuration Single
Power Dissipation 1.5kW
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Max Reverse Leakage Current 5μA
Voltage - Clamping (Max) @ Ipp 19.9V
Clamping Voltage 19.9V
Peak Pulse Current 75.4A
Reverse Standoff Voltage 12V
Max Surge Current 75.4A
Peak Pulse Power 1.5kW
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 13.3V
Bidirectional Channels 1
Reverse Breakdown Voltage 13.3V
Max Breakdown Voltage 14.7V
Max Junction Temperature (Tj) 150°C
Dimensions
Height 2.62mm
Length 7.0866mm
Width 6.22mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
