SMBG30-E3/52
RoHS
RoHS compliant
RoHS compliantPackage DO-215AA, SMB Gull Wing
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 30V 53.5V DO215AA
PDF
/
Inventory: 8176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of Unidirectional Channels 1
Reverse Breakdown Voltage 33.3V
Breakdown Voltage 33.3V
Unidirectional Channels 1
Test Current 1mA
Peak Pulse Power 600W
Max Surge Current 100A
Reverse Standoff Voltage 30V
Peak Pulse Current 11.2A
Voltage - Reverse Standoff (Typ) 30V
Clamping Voltage 53.5V
Voltage - Clamping (Max) @ Ipp 53.5V
Current - Peak Pulse (10/1000μs) 11.2A
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 33.3V
Power Line Protection No
Leakage Current 1μA
Number of Channels 1
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 30V
Base Part Number SMBG
Applications General Purpose
Composition Zener
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TransZorb?
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Supplier Device Package DO-215AA (SMBG)
Number of Pins 2
Package / Case DO-215AA, SMB Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
