SMB8J24CA-M3/52
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
DO-214AA SMB TransZorb? 1 Surface Mount Zener Tvs Diode 38.9V 20.6A 800W -55C~150C TJ
PDF
/
Inventory: 8619
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 33 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2016
Series TransZorb?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-C2
Number of Elements 1
Polarity BIDIRECTIONAL
Configuration SINGLE
Power Line Protection No
Voltage - Breakdown (Min) 26.7V
Current - Peak Pulse (10/1000μs) 20.6A
Clamping Voltage 38.9V
Voltage - Reverse Standoff (Typ) 24V
Peak Pulse Current 20.6A
Reverse Standoff Voltage 24V
Peak Pulse Power 800W
Bidirectional Channels 1
Compliance
RoHS Status ROHS3 Compliant
