SM15T33CA-E3/57T
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS BIDIR 1.5KW 33V 5% SMC
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.6952
≥1 USD $0.6952
≥10 USD $0.60544
≥100 USD $0.41932
Inventory: 1152
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Breakdown Voltage 31.4V
Breakdown Voltage 31.4V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 1.5kW
Max Surge Current 200A
Reverse Standoff Voltage 28.2V
Peak Pulse Current 169A
Clamping Voltage 45.7V
Voltage - Clamping (Max) @ Ipp 45.7V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 33A
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Leakage Current 1μA
Number of Channels 1
Number of Elements 1
Operating Supply Voltage 28.2V
Pin Count 2
Base Part Number SM15T*
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Additional Feature EXCELLENT CLAMPING CAPABILITY ,HIGH RELIABILITY
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SM15T, TransZorb?
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 29 Weeks
