P6SMB27A-E3/5B
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 23.1VWM 37.5VC SMB
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.08075
≥1 USD $0.08075
≥10 USD $0.0665
≥100 USD $0.0646
≥500 USD $0.0627
≥1000 USD $0.05985
Inventory: 8189
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2011
Series P6SMB, TransZorb?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number P6SMB
Pin Count 2
Operating Supply Voltage 23.1V
Number of Elements 1
Leakage Current 1μA
Power Dissipation-Max 5W
Element Configuration Single
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 600W
Max Reverse Leakage Current 1μA
Voltage - Clamping (Max) @ Ipp 37.5V
Clamping Voltage 37.5V
Peak Pulse Current 16A
Reverse Standoff Voltage 23.1V
Max Surge Current 100A
Peak Pulse Power 600W
Direction Unidirectional
Test Current 1mA
Breakdown Voltage 25.7V
Reverse Breakdown Voltage 25.7V
Compliance
RoHS Status ROHS3 Compliant
