1N6292A-E3/54
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 64.1VWM 104VC 1.5KE
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.626199
≥1 USD $0.626199
≥10 USD $0.590746
≥100 USD $0.55731
≥500 USD $0.525767
≥1000 USD $0.496006
Inventory: 1131
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Published 2011
Series TransZorb?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY
Subcategory Transient Suppressors
Max Power Dissipation 1.5kW
Technology AVALANCHE
Terminal Form WIRE
Pin Count 2
Operating Supply Voltage 64.1V
Number of Elements 1
Leakage Current 1μA
Element Configuration Single
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Max Reverse Leakage Current 1μA
Voltage - Clamping (Max) @ Ipp 104V
Clamping Voltage 104V
Peak Pulse Current 14.6A
Reverse Standoff Voltage 64.1V
Max Surge Current 14.6A
Peak Pulse Power 1.5kW
Direction Unidirectional
Test Current 1mA
Unidirectional Channels 1
Breakdown Voltage 71.3V
Reverse Breakdown Voltage 71.3V
Compliance
RoHS Status ROHS3 Compliant
