TPD6E001RSER
RoHS
RoHS compliant
RoHS compliantPackage 10-UFQFN
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5V 10UQFN
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2751
≥1 USD $1.2751
≥10 USD $1.20293
≥100 USD $1.13484
≥500 USD $1.0706
≥1000 USD $1.01
≥3000 USD $0.95283
Inventory: 3095
Minimum: 1
-
+
Technical Details
Technical
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Depth 2mm
Base Part Number TPD6E001
Pin Count 10
Operating Supply Voltage 5.5V
Number of Elements 1
Working Voltage 5.5V
Polarity Bidirectional
Configuration SINGLE
Number of Channels 6
Interface LVDS, USB
Leakage Current 1nA
Power Line Protection Yes
Max Reverse Leakage Current 1nA
Clamping Voltage 105.5V
Voltage - Reverse Standoff (Typ) 5V Max
Peak Pulse Current 10A
Reverse Standoff Voltage 5V
Direction Unidirectional
Test Current 10mA
Breakdown Voltage 11V
JEDEC-95 Code MO-228UEFD
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 1.5pF
HTS Code 8542.39.00.01
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Steering (Rail to Rail)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height 600μm
Length 1.5mm
Width 2mm
Thickness 550μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Weight 7.002332mg
Number of Pins 10
Surface Mount YES
Package / Case 10-UFQFN
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
