TPD4E1B06DRLR

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-563, SOT-666
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 5.5V 14.5V 6SOT
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.31592
≥100 USD $0.219736
≥500 USD $0.171565
≥1000 USD $0.139454
≥3000 USD $0.124661
Inventory: 18076
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 550μm
Width 1.2mm
Length 1.6mm
Height 600μm

Technical

Direction Bidirectional
Peak Pulse Power 45W
Reverse Standoff Voltage 5.5V
Peak Pulse Current 3A
Voltage - Reverse Standoff (Typ) 5.5V Max
Clamping Voltage 14.5V
Voltage - Clamping (Max) @ Ipp 14.5V Typ
Current - Peak Pulse (10/1000μs) 3A 8/20μs
Voltage - Breakdown (Min) 7V
Power Line Protection No
Interface LVDS, USB
Number of Channels 4
Configuration COMPLEX
Working Voltage 5.5V
Number of Elements 4
Base Part Number TPD4E1B06
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Capacitance 950FF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Steering (Rail to Rail)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA

Physical

Diode Element Material SILICON
Number of Pins 6
Package / Case SOT-563, SOT-666
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
