TPD4E002DRL2

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-553
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 3V SOT5
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.32208
≥100 USD $0.224136
≥500 USD $0.175014
≥1000 USD $0.142252
≥3000 USD $0.127169
Inventory: 3991
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 550μm
Width 1.2mm
Length 1.6mm
Height 600μm

Technical

Number of Unidirectional Channels 4
Rep Pk Reverse Voltage-Max 5V
Breakdown Voltage 6.1V
Direction Unidirectional
Peak Pulse Power 35W
Reverse Standoff Voltage 3V
Power - Peak Pulse 35W
Power Line Protection No
Leakage Current 100nA
Interface GPIO, USB
Number of Elements 4
Pin Count 5
Base Part Number TPD4E002
Depth 1.2mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Subcategory Transient Suppressors
Capacitance 11pF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA

Physical

Diode Element Material SILICON
Number of Pins 5
Surface Mount YES
Package / Case SOT-553
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
