TPD4E001DRLR
RoHS
RoHS compliant
RoHS compliantPackage SOT-563, SOT-666
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5.5V 6SOT
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.11424
≥1 USD $0.11424
≥500 USD $0.084
≥1000 USD $0.07
≥2000 USD $0.06422
≥5000 USD $0.06002
Inventory: 58960
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 550μm
Width 1.2mm
Length 1.6mm
Height 600μm
Technical
Ambient Temperature Range High 85°C
Max Junction Temperature (Tj) 150°C
Max Breakdown Voltage 11V
JEDEC-95 Code MO-178AB
Breakdown Voltage 11V
Unidirectional Channels 4
Direction Unidirectional
Peak Pulse Power 100W
Reverse Standoff Voltage 5.5V
Peak Pulse Current 5.5A
Voltage - Reverse Standoff (Typ) 5.5V Max
Clamping Voltage 17V
Power Line Protection Yes
Leakage Current 1nA
Interface Ethernet, LVDS, USB
Number of Channels 4
Configuration SINGLE
Working Voltage 5.5V
Number of Elements 1
Operating Supply Voltage 950mV
Pin Count 6
Base Part Number TPD4E001
Depth 1.2mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 100W
Subcategory Transient Suppressors
Capacitance 1.5pF
Applications Ethernet
Type Steering (Rail to Rail)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Diode Element Material SILICON
Weight 2.806603mg
Number of Pins 6
Package / Case SOT-563, SOT-666
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
