TPD1E6B06DPLT
RoHS
/
Package 0201 (0603 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5VWM 14VC 2X2SON
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.682
≥100 USD $0.471944
Inventory: 1648
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Thickness 300μm
Width 300μm
Length 600μm
Height 320μm
Technical
Rep Pk Reverse Voltage-Max 5V
Bidirectional Channels 1
Breakdown Voltage 6V
Peak Pulse Power 50W
Reverse Standoff Voltage 5V
Peak Pulse Current 5A
Voltage - Reverse Standoff (Typ) 5V Max
Clamping Voltage 14V
Current - Peak Pulse (10/1000μs) 5A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 100nA
Number of Channels 1
Polarity Bidirectional
Working Voltage 5V
Base Part Number TPD1E6B06
Peak Reflow Temperature (Cel) 260
Max Power Dissipation 50W
Subcategory Transient Suppressors
Capacitance 6pF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 2
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
