TPD1E1B04DPYT
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1006 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 3.6V 8.5V 2X1SON
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.63096
≥100 USD $0.490864
Inventory: 7815
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 370μm
Width 1mm
Length 600μm
Height 450μm
Technical
Non-rep Peak Rev Power Dis-Max 50W
Capacitance @ Frequency 1pF @ 1MHz
Rep Pk Reverse Voltage-Max 3.6V
Bidirectional Channels 1
Breakdown Voltage 6.4V
Voltage - Reverse Standoff (Typ) 3.6V Max
Voltage - Clamping (Max) @ Ipp 8.5V Typ
Current - Peak Pulse (10/1000μs) 6.3A 8/20μs
Power - Peak Pulse 50W
Voltage - Breakdown (Min) 6.4V Typ
Power Line Protection No
Interface Ethernet, LVDS, USB
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
Base Part Number TPD1E1B04
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Capacitance 1pF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Diode Element Material SILICON
Number of Pins 2
Surface Mount YES
Package / Case 0402 (1006 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 12 Weeks
