TPD1E10B09DPYR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 0402 (1006 Metric)
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 9V 20V 2X1SON
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.24112
≥100 USD $0.121792
≥500 USD $0.107923
≥1000 USD $0.083987
≥3000 USD $0.075178
Inventory: 70067
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Thickness 370μm
Width 1mm
Length 600μm
Height 450μm

Technical

ESD Protection Yes
Rep Pk Reverse Voltage-Max 9V
Breakdown Voltage 9.5V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 90W
Reverse Standoff Voltage 9V
Peak Pulse Current 4.5A
Voltage - Reverse Standoff (Typ) 9V Max
Clamping Voltage 20V
Max Reverse Leakage Current 100nA
Current - Peak Pulse (10/1000μs) 4.5A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 100nA
Number of Channels 1
Working Voltage 9V
Number of Elements 1
Operating Supply Voltage 9V
Case Code (Metric) 0402
Base Part Number TPD1E10B09
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 10pF
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA

Physical

Manufacturer Package Identifier DPY (R-PX1SON-N2)
Diode Element Material SILICON
Number of Pins 2
Surface Mount YES
Package / Case 0402 (1006 Metric)
Mounting Type Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
