TPD1E0B04DPYR
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1006 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 3.6V 19V 2X1SON
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.26224
≥100 USD $0.132088
≥500 USD $0.117093
≥1000 USD $0.091124
≥3000 USD $0.081558
Inventory: 39674
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Surface Mount YES
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications General Purpose
Technology AVALANCHE
Terminal Position DUAL
Base Part Number TPD1E0B04
Number of Elements 1
Polarity BIDIRECTIONAL
Configuration SINGLE
Interface USB
Power Line Protection No
Voltage - Breakdown (Min) 6.7V Typ
Power - Peak Pulse 15W
Current - Peak Pulse (10/1000μs) 1.7A 8/20μs
Voltage - Clamping (Max) @ Ipp 19V
Voltage - Reverse Standoff (Typ) 3.6V
Breakdown Voltage 6.7V
Bidirectional Channels 1
Rep Pk Reverse Voltage-Max 3.6V
Capacitance @ Frequency 0.15pF @ 1MHz
Dimensions
Height 450μm
Length 600μm
Width 1mm
Thickness 370μm
Compliance
RoHS Status ROHS3 Compliant
