TPD1E04U04DPYR
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1006 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 3.6V 8.9V 2X1SON
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.27632
≥100 USD $0.165616
≥500 USD $0.153314
≥1000 USD $0.104254
≥3000 USD $0.095982
Inventory: 5233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 370μm
Width 1mm
Length 600μm
Height 450μm
Technical
Number of Unidirectional Channels 1
Capacitance @ Frequency 0.5pF @ 1MHz
Breakdown Voltage 6.2V
Peak Pulse Power 19W
Reverse Standoff Voltage 3.6V
Peak Pulse Current 2.5A
Voltage - Reverse Standoff (Typ) 3.6V Max
Clamping Voltage 8.9V
Current - Peak Pulse (10/1000μs) 2.5A 8/20μs
Voltage - Breakdown (Min) 4.5V
Power Line Protection Yes
Interface HDMI, USB
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
Base Part Number TPD1E04U04
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology AVALANCHE
Additional Feature ULTRA LOW CAPACITANCE
Applications HDMI
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Steering (Rail to Rail)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case 0402 (1006 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
Alternative Model
