STIEC45-26ACS
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 26VWM 45VC DO214AB
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.53495
≥1 USD $3.53495
≥10 USD $2.90035
≥100 USD $2.8101
≥500 USD $2.7189
≥1000 USD $2.62865
Inventory: 29006
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Bidirectional Channels 1
Reverse Standoff Voltage 26V
Peak Pulse Current 500A
Clamping Voltage 45V
Current - Peak Pulse (10/1000μs) 500A 8/20μs
Voltage - Breakdown (Min) 28.9V
Power Line Protection No
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-C2
Base Part Number STIEC45
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series STIEC, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 8 months ago)
