SMTY5.0A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5VWM 9VC SMA
PDF
/
Inventory: 1583
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series SMTY, Transky?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Applications General Purpose
Subcategory Transient Suppressors
Power Rating 600W
Voltage - Rated DC 5V
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number SMTY
Pin Count 2
Operating Supply Voltage 5V
Number of Elements 1
Polarity Unidirectional
Configuration SINGLE
Leakage Current 10μA
Power Dissipation-Max 4W
Power Line Protection No
Voltage - Clamping (Max) @ Ipp 9V
Clamping Voltage 9V
Peak Pulse Current 43.5A
Reverse Standoff Voltage 5V
Max Surge Current 43.5A
Peak Pulse Power 600W
Test Current 10mA
Breakdown Voltage 6.4V
Rep Pk Reverse Voltage-Max 5V
Reverse Breakdown Voltage 6.4V
Number of Unidirectional Channels 1
Dimensions
Height 2.03mm
Length 5.6mm
Width 2.95mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
