SMCJ30CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
STMicroelectronics SMCJ30CA-TR, Bi-Directional TVS Diode, 1500W, 2-Pin DO-214AB
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.5456
≥100 USD $0.37752
≥500 USD $0.31548
≥1000 USD $0.268488
Inventory: 871
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series SMCJ, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Capacitance 2.5nF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 30V
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number SMCJ
Pin Count 2
Operating Supply Voltage 30V
Number of Elements 1
Polarity Bidirectional
Number of Channels 1
Leakage Current 200nA
Element Configuration Single
Power Dissipation 1.5kW
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 156A 8/20μs
Max Reverse Leakage Current 200nA
Clamping Voltage 64.3V
Peak Pulse Current 156A
Reverse Standoff Voltage 30V
Max Surge Current 156A
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 33.3V
Reverse Breakdown Voltage 33.3V
Max Breakdown Voltage 33.3V
Dimensions
Height 2.45mm
Length 7.15mm
Width 6.25mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
