SMCJ12A-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
DO-214AB SMC SMCJ TRANSIL? 1 Surface Mount Zener Tvs Diode 13.3V 394A 8/20mus 1.5kW 5.25nF
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.71456
≥100 USD $0.555456
≥500 USD $0.470818
≥1000 USD $0.383539
Inventory: 1018
Minimum: 1
-
+
Technical Details
Physical
Number of Pins 2
Diode Element Material SILICON
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series SMCJ, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Number of Unidirectional Channels 1
Max Breakdown Voltage 14V
Reverse Breakdown Voltage 13.3V
Breakdown Voltage 13.3V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 12V
Peak Pulse Current 394A
Clamping Voltage 25.3V
Current - Peak Pulse (10/1000μs) 394A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Power Dissipation 1.5kW
Leakage Current 200nA
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 12V
Pin Count 2
Base Part Number SMCJ
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 5.25nF
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
