SMCJ10CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
DO-214AB SMC SMCJ TRANSIL? 1 Surface Mount Zener Tvs Diode 11.1V 461A 8/20mus 1.5kW 6nF
PDF
/
Buying Options
Total Price: USD $2.04
Unit Price: USD $2.03585
≥1 USD $2.03585
≥10 USD $1.67105
≥100 USD $1.6188
≥500 USD $1.56655
≥1000 USD $1.5143
Inventory: 16108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Reverse Breakdown Voltage 11.1V
Breakdown Voltage 11.1V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 10V
Peak Pulse Current 461A
Clamping Voltage 21.7V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 461A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Power Dissipation-Max 6.5W
Leakage Current 200nA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 10V
Pin Count 2
Base Part Number SMCJ
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 10V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 6nF
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series SMCJ, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
