SMC30J24A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24VWM 38.9VC SMC
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $0.87824
≥100 USD $0.682792
≥500 USD $0.578723
≥1000 USD $0.471425
Inventory: 1423
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Non-rep Peak Rev Power Dis-Max 3000W
Breakdown Voltage 26.7V
Unidirectional Channels 1
Direction Unidirectional
Peak Pulse Power 3kW
Reverse Standoff Voltage 24V
Peak Pulse Current 77A
Clamping Voltage 38.9V
Voltage - Clamping (Max) @ Ipp 38.9V
Power - Peak Pulse 3000W 3kW
Power Line Protection No
Configuration SINGLE
Working Voltage 24V
Number of Elements 1
Pin Count 2
Base Part Number SMC30J
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3kW
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SMC30J, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
