SMC30J22CA

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 22VWM 35.5VC SMC
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.25844
≥1 USD $1.25844
≥10 USD $1.227045
≥100 USD $1.206114
Inventory: 23
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Non-rep Peak Rev Power Dis-Max 3000W
Bidirectional Channels 1
Breakdown Voltage 24.4V
Direction Bidirectional
Peak Pulse Power 3kW
Reverse Standoff Voltage 22V
Peak Pulse Current 85A
Clamping Voltage 35.5V
Voltage - Clamping (Max) @ Ipp 35.5V
Power - Peak Pulse 3000W 3kW
Power Line Protection No
Configuration SINGLE
Working Voltage 22V
Number of Elements 1
Pin Count 2
Base Part Number SMC30J
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3kW
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SMC30J, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 months ago)
