SMC30J10CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 10VWM 17VC SMC
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.1352
≥1 USD $1.1352
≥10 USD $0.92576
≥100 USD $0.719752
≥500 USD $0.610051
≥1000 USD $0.496945
Inventory: 2559
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Cut Tape (CT)
Series SMC30J, TRANSIL?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Applications General Purpose
Max Power Dissipation 3kW
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Depth 6.25mm
Base Part Number SMC30J
Pin Count 2
Number of Elements 1
Working Voltage 10V
Leakage Current 200nA
Element Configuration Single
Power Line Protection No
Power - Peak Pulse 3000W 3kW
Voltage - Clamping (Max) @ Ipp 17V
Clamping Voltage 17V
Peak Pulse Current 176A
Reverse Standoff Voltage 10V
Peak Pulse Power 3kW
Direction Bidirectional
Breakdown Voltage 11.1V
Bidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 3000W
Dimensions
Length 7.15mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
