SMB6F70AY
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Circuit Protection / TVS - Diodes
Description
AUTOMOTIVE 600 W, 70 V TVS IN SM
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.3168
≥100 USD $0.22
≥500 USD $0.171758
≥1000 USD $0.139612
≥3000 USD $0.12481
Inventory: 9450
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 70V
Voltage - Clamping (Max) @ Ipp 113V
Current - Peak Pulse (10/1000μs) 5.5A
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 77.9V
Power Line Protection No
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SMB6FxxAY
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
