SMAJ5.0CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5V 13.4V SMA
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.33528
≥100 USD $0.20108
≥500 USD $0.186208
≥1000 USD $0.126614
≥3000 USD $0.116565
Inventory: 21748
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 2.9mm
Length 4.6mm
Height 2.65mm
Technical
Max Junction Temperature (Tj) 150°C
Max Forward Surge Current (Ifsm) 40A
ESD Protection Yes
Max Breakdown Voltage 6.74V
Series Resistance 49mOhm
Reverse Breakdown Voltage 6.4V
Max Reverse Voltage (DC) 5V
Breakdown Voltage 6.4V
Test Current 10mA
Direction Bidirectional
Peak Pulse Power 400W
Max Surge Current 10mA
Reverse Standoff Voltage 5V
Peak Pulse Current 43.5A
Clamping Voltage 9.2V
Voltage - Clamping (Max) @ Ipp 13.4V
Max Reverse Leakage Current 20μA
Current - Peak Pulse (10/1000μs) 174A 8/20μs
Power Line Protection No
Power Dissipation 400W
Element Configuration Single
Leakage Current 20μA
Number of Channels 1
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 2
Base Part Number SMAJ
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3.3W
Voltage - Rated DC 5V
Power Rating 400W
Subcategory Transient Suppressors
Capacitance 3.5nF
Additional Feature MOS COMPATIBLE
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMAJ, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
