SMAJ130CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS Diodes - Transient Voltage Suppressors 400W 130V Bidirect
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.36575
≥1 USD $0.36575
≥10 USD $0.3002
≥100 USD $0.2907
≥500 USD $0.2812
≥1000 USD $0.2717
Inventory: 65185
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series SMAJ, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Applications General Purpose
Additional Feature MOS COMPATIBLE
Capacitance 145pF
Subcategory Transient Suppressors
Power Rating 400W
Voltage - Rated DC 130V
Max Power Dissipation 400W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Base Part Number SMAJ
Pin Count 2
Operating Supply Voltage 130V
Number of Elements 1
Polarity Bidirectional
Leakage Current 200nA
Element Configuration Single
Power Dissipation 3.3W
Power Line Protection No
Current - Peak Pulse (10/1000μs) 9A 8/20μs
Max Reverse Leakage Current 200nA
Clamping Voltage 265V
Peak Pulse Current 9A
Reverse Standoff Voltage 130V
Max Surge Current 1mA
Peak Pulse Power 400W
Test Current 1mA
Breakdown Voltage 144V
Reverse Breakdown Voltage 144V
Max Breakdown Voltage 152V
ESD Protection Yes
Dimensions
Height 2.45mm
Length 4.6mm
Width 2.9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
