SMA6T7V6AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 6.5VWM 14.5VC SMA
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.556811
≥1 USD $0.556811
≥10 USD $0.525294
≥100 USD $0.495557
≥500 USD $0.467515
≥1000 USD $0.441048
Inventory: 3833
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 4.6mm
Technical
Breakdown Voltage 7.2V
Unidirectional Channels 1
Direction Unidirectional
Peak Pulse Power 600W
Max Surge Current 56A
Reverse Standoff Voltage 6.5V
Peak Pulse Current 276A
Clamping Voltage 14.5V
Voltage - Clamping (Max) @ Ipp 14.5V
Current - Peak Pulse (10/1000μs) 276A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 20μA
Working Voltage 6.5V
Number of Elements 1
Operating Supply Voltage 6.5V
Base Part Number SMA6T
Depth 2.95mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 600W
Additional Feature LOW LEAKAGE CURRENT
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SMA6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
