SMA6T56CAY

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 48VWM 100VC SMA
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.84216
≥100 USD $0.654984
≥500 USD $0.555139
≥1000 USD $0.452223
≥3000 USD $0.425718
Inventory: 13506
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Rep Pk Reverse Voltage-Max 47.6V
Bidirectional Channels 1
Breakdown Voltage 56V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Reverse Standoff Voltage 48V
Peak Pulse Current 40A
Voltage - Reverse Standoff (Typ) 48V
Clamping Voltage 100V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Voltage - Breakdown (Min) 53.3V
Power Line Protection No
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PDSO-C2
Pin Count 2
Base Part Number SMA6T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature LOW LEAKAGE CURRENT
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SMA6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ

Physical

Diode Element Material SILICON
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
