SMA6T47CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 40VWM 73.6VC SMA
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
≥10 USD $0.59752
≥100 USD $0.413776
≥500 USD $0.345717
≥1000 USD $0.294228
≥3000 USD $0.262046
Inventory: 20756
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SMA6TY, TRANSIL?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Applications Automotive
Additional Feature LOW LEAKAGE CURRENT
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Depth 2.95mm
Base Part Number SMA6T
Number of Elements 1
Working Voltage 40V
Leakage Current 200nA
Element Configuration Single
Power Line Protection No
Voltage - Breakdown (Min) 44.4V
Current - Peak Pulse (10/1000μs) 48A 8/20μs
Max Reverse Leakage Current 200nA
Clamping Voltage 73.6V
Peak Pulse Current 48A
Reverse Standoff Voltage 40V
Peak Pulse Power 600W
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 46.7V
Bidirectional Channels 1
Dimensions
Length 4.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
