SMA6T28AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Uni-Dir 24V 600W Automotive 2-Pin SMA T/R
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.78408
≥100 USD $0.609752
≥500 USD $0.516859
≥1000 USD $0.421036
≥3000 USD $0.396361
Inventory: 3448
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 4.6mm
Technical
Number of Unidirectional Channels 1
Breakdown Voltage 28.1V
Direction Unidirectional
Peak Pulse Power 600W
Reverse Standoff Voltage 24V
Peak Pulse Current 80A
Clamping Voltage 44.3V
Current - Peak Pulse (10/1000μs) 80A 8/20μs
Voltage - Breakdown (Min) 26.7V
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Polarity Unidirectional
Working Voltage 24V
Number of Elements 1
Pin Count 2
Base Part Number SMA6T
Depth 2.95mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature LOW LEAKAGE CURRENT
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SMA6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
