SMA6T18AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 15.3VWM 32.3VC SMA
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
≥10 USD $0.54472
≥100 USD $0.377344
≥500 USD $0.315304
≥1000 USD $0.268347
≥3000 USD $0.238999
Inventory: 4523
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 4.6mm
Technical
Number of Unidirectional Channels 1
Breakdown Voltage 18V
Direction Unidirectional
Peak Pulse Power 600W
Max Surge Current 34A
Reverse Standoff Voltage 15.3V
Peak Pulse Current 123A
Clamping Voltage 32.3V
Current - Peak Pulse (10/1000μs) 123A 8/20μs
Voltage - Breakdown (Min) 17.1V
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Polarity Unidirectional
Number of Elements 1
Base Part Number SMA6T
Depth 2.95mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature LOW LEAKAGE CURRENT
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SMA6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
