SMA6J85CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 85VWM 146VC SMA
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.484
≥100 USD $0.335192
≥500 USD $0.280051
≥1000 USD $0.238339
≥3000 USD $0.212274
Inventory: 4356
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series SMA6J, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Applications General Purpose
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number SMA6J
Pin Count 2
JESD-30 Code R-PDSO-C2
Number of Elements 1
Polarity BIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 4W
Power Line Protection No
Voltage - Breakdown (Min) 94V
Power - Peak Pulse 600W
Current - Peak Pulse (10/1000μs) 22.5A 8/20μs
Voltage - Clamping (Max) @ Ipp 146V
Voltage - Reverse Standoff (Typ) 85V
Breakdown Voltage 99V
Bidirectional Channels 1
Rep Pk Reverse Voltage-Max 85V
Non-rep Peak Rev Power Dis-Max 600W
Compliance
RoHS Status ROHS3 Compliant
