SMA6J48CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 48VWM 88.4VC SMA
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.44
≥100 USD $0.304744
≥500 USD $0.254654
≥1000 USD $0.216726
≥3000 USD $0.193019
Inventory: 14769
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Max Breakdown Voltage 58.9V
Reverse Breakdown Voltage 53.3V
Breakdown Voltage 56.1V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 40A
Reverse Standoff Voltage 48V
Peak Pulse Current 40A
Voltage - Reverse Standoff (Typ) 48V
Clamping Voltage 88.4V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Power Line Protection No
Power Dissipation 600W
Element Configuration Single
Leakage Current 200nA
Number of Channels 1
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 48V
Pin Count 2
Base Part Number SMA6J
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMA6J, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
