SMA6F13A
RoHS
RoHS compliant
RoHS compliantPackage DO-221AC, SMA Flat Leads
Category Circuit Protection / TVS - Diodes
Description
600 W TVS IN SMA FLAT
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.29392
≥100 USD $0.176352
≥500 USD $0.16331
≥1000 USD $0.111056
Inventory: 1753
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 600W
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 13V
Voltage - Clamping (Max) @ Ipp 21.5V
Current - Peak Pulse (10/1000μs) 29A
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 14.4V
Power Line Protection No
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-F2
Base Part Number SMA6F
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMA6F, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-221AC, SMA Flat Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
