SMA6F11A
RoHS
RoHS compliant
RoHS compliantPackage DO-221AC, SMA Flat Leads
Category Circuit Protection / TVS - Diodes
Description
600 W TVS IN SMA FLAT
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 1594
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case DO-221AC, SMA Flat Leads
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series SMA6F, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Technology AVALANCHE
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Base Part Number SMA6F
JESD-30 Code R-PDSO-F2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Line Protection No
Voltage - Breakdown (Min) 12.3V
Power - Peak Pulse 600W
Current - Peak Pulse (10/1000μs) 33.8A
Voltage - Clamping (Max) @ Ipp 18V
Voltage - Reverse Standoff (Typ) 11V
Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 600W
Compliance
RoHS Status ROHS3 Compliant
